Category
Feature
Specifications
| Category | Feature | Specification Details |
|---|---|---|
| GPU Engine Specs | Graphics Processor | NVIDIA GeForce RTX 4060 (AD107) |
| GPU Engine Specs | CUDA Cores | 3,072 |
| GPU Engine Specs | Engine Clock (Default Mode) | Boost Clock: 2505 MHz |
| GPU Engine Specs | Engine Clock (OC Mode) | Boost Clock: 2535 MHz |
| GPU Engine Specs | AI Performance | 246 AI TOPS |
| Memory Specs | Video Memory | 8GB GDDR6 |
| Memory Specs | Memory Speed | 17 Gbps |
| Memory Specs | Memory Interface | 128-bit |
| Memory Specs | Memory Bandwidth | 272 GB/s |
| Display Support | Digital Max Resolution | $7680 \times 4320$ (8K Ultra HD) |
| Display Support | Maximum Displays | Quad Display Support (Up to 4 screens) |
| Display Support | HDCP Support | Yes (Version 2.3) |
| Connectivity | HDMI Interface | 1x Native HDMI 2.1a |
| Connectivity | DisplayPort Interface | 3x Native DisplayPort 1.4a |
| Power Specs | Power Consumption (TDP) | ~115W |
| Power Specs | Recommended PSU | 550W (Based on fully configured rigs) |
| Power Specs | Power Connectors | 1x 8-pin PCIe cable |
| API Support | DirectX Support | DirectX 12 Ultimate |
| API Support | OpenGL Support | OpenGL 4.6 |
| Physical Specs | Card Dimensions | 227.2 x 123.24 x 49.6 mm |
| Physical Specs | Slot Width | 2.5 Slot Design |
| Physical Specs | Cooling Solution | Dual Axial-tech Fans with 0dB Technology |
| Physical Specs | Aesthetics / Color | All-White Shroud and Backplate |
| Warranty | Manufacturer Warranty | 3 Years Limited Warranty |
