| Basic Information | |
|---|---|
| Supported CPU | Supports Intel Core Ultra Processors (Series 2) LGA 1851 |
| Chipset | INTEL H810 |
| Form Factor | mATX 220mmx243.84mm |
| Audio | Realtek ALC897 Codec 7.1-Channel High Definition Audio |
| Expansion Slots | |
| PCI | 1x PCI-E x16 slot 2x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x1 (From Chipset) |
| M.2 Socket | 1x M.2 M.2_1 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices |
| Memory | |
| Type | DDR5 |
| Slots | 2 |
| Supported Memory | Memory Support DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MT/s Max. overclocking frequency: • 1DPC 1R Max speed up to 6400+ MT/s • 1DPC 2R Max speed up to 6400+ MT/s Supports Intel POR Speed and JEDEC Speed Supports Memory Overclocking and Intel XMP 3.0 Supports Dual-Controller Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM |
| Maximum Memory | 128GB |
| Graphics | |
| Graphics | 1x HDMI Support HDMI 2.1, maximum resolution of 4K 60Hz 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz |
| Connector & Ports | |
| HDMI | 1x HDMI 2.1 |
| Display Port (s) | 1x DisplayPort 1.4 |
| USB (s) | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 1x USB 10Gbps Type C (Front) 1x USB 20Gbps Type C (Rear) |
| LAN Port (s) | Realtek 8126 5Gbps LAN |
| Wireless Communication module | Wi-Fi 6E module The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.3, FIPS, FISMA |
| Supported Storage | 1x M.2 M.2_1 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices 4x SATA 6G |
| Audio | 1x Front Audio (JAUD) |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports |
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) |
| Others | |
| Special Features | 4x EZ Debug LED 1x EZ Memory Detection LED |
| Warranty Information | |
| Manufacturing Warranty | 3 Year warranty |
MSI H810M GAMING WIFI6E LGA 1851 mATX Motherboard
Price:
19,900৳
Status: In Stock
Product
Code: #851
Category:
Motherboard
Tags:
MotherBoard
The MSI H810M GAMING WIFI6E LGA 1851 mATX Motherboard is a high-performance motherboard designed for Intel Core Ultra (Series 2) processors. Built on the Intel H810 chipset, it supports up to 128GB DDR5 memory, PCIe 5.0 graphics, PCIe 4.0 M.2 storage, Wi-Fi 6E, 5GbE LAN, and Bluetooth 5.3 for ultra-fast connectivity. Featuring MSI Core Boost, Memory Boost, Frozr Guard cooling, and Audio Boost, this motherboard delivers reliable performance for gaming, content creation, and everyday computing.
19,900৳
Cash / Online Price
Online / Cash Payment
1,658৳/month
Regular Price: 19,900৳
0% EMI up to 12 Months
Specification
Description
MSI H810M GAMING WIFI6E LGA 1851 mATX Motherboard
The MSI H810M GAMING WIFI6E LGA 1851 mATX Motherboard is a feature-rich gaming motherboard engineered to deliver exceptional performance, stability, and connectivity for modern desktop PCs. Powered by the Intel H810 chipset, it supports the latest Intel Core Ultra (Series 2) processors on the LGA 1851 socket, making it an excellent foundation for next-generation gaming, content creation, and professional workloads. Its compact micro-ATX form factor offers an ideal balance of expandability and space efficiency for a wide range of PC builds.
The motherboard supports dual-channel DDR5 memory with capacities up to 128GB and overclocked speeds exceeding 6400 MT/s, ensuring faster data transfer, improved multitasking, and enhanced application performance. With Intel XMP 3.0, users can easily optimize memory settings for maximum speed. MSI's Core Boost and Memory Boost technologies, combined with a durable 6-layer server-grade PCB and 6 P-PAK power system, provide stable power delivery and reliable system operation under demanding workloads.
To maintain optimal thermal performance, the MSI H810M GAMING WIFI6E features the advanced Frozr Guard cooling system, including an extended heatsink, 7W/mK MOSFET thermal pads, additional choke thermal pads, and M.2 Shield Frozr for improved SSD cooling. Expansion options include a PCIe 5.0 x16 slot for the latest graphics cards, a PCIe 4.0 x4 M.2 slot for ultra-fast NVMe SSDs, and four SATA 6Gb/s ports for additional storage devices.
For high-speed networking, the motherboard is equipped with Realtek 5GbE LAN, Wi-Fi 6E, and Bluetooth 5.3, providing fast, stable, and low-latency connectivity for online gaming, streaming, and professional applications. Display connectivity includes HDMI 2.1 and DisplayPort 1.4, supporting up to 4K resolution at 60Hz with compatible processors. MSI's Audio Boost, powered by the Realtek ALC897 codec, delivers immersive 7.1-channel HD audio for an enhanced gaming and entertainment experience.
The rear I/O panel includes a USB 20Gbps Type-C port, multiple USB 5Gbps and USB 2.0 ports, while the front panel supports an additional USB 10Gbps Type-C connector. DIY-friendly features such as EZ M.2 Clip II, EZ PCIe Clip II, EZ Antenna, EZ Debug LEDs, and EZ Memory Detection LEDs simplify installation and troubleshooting. With RGB lighting support, Windows 11 compatibility, premium build quality, and next-generation connectivity, the MSI H810M GAMING WIFI6E LGA 1851 mATX Motherboard is an outstanding choice for gamers and PC enthusiasts looking for a powerful and future-ready platform.
Meta Title
What is the price of MSI H810M GAMING WIFI6E LGA 1851 mATX Motherboard in Bangladesh?
The latest price of MSI H810M GAMING WIFI6E LGA 1851 mATX Motherboard in Bangladesh is 19,900৳. You can buy the MSI H810M GAMING WIFI6E LGA 1851 mATX Motherboard at best price from our website or visit any of our showrooms.
